ASR 9901 Fan Tray
Condition: NOB
RMA Warranty
Description
Cisco ASR 9000 Series Aggregation Services Routers deliver exceptional scale, service flexibility, and high availability to Carrier Ethernet transport networks. The router is powered by widely deployed Cisco IOS XR 64 bit operating system, an innovative self-healing, distributed operating system designed for always-on operation. The ASR 9901 sets a new standard for Layer 2 and Layer 3 10GE/1GE service density and scale to support large-scale aggregation, Data Center Interconnect (DCI), and Satellite Network Virtualization (nV) System mode on the ASR 9000 Series Router. The ASR 9901 also supports industry leading MAC-SEC encryption on all its port speeds. These versatile capabilities help operators qualify and stock one type of chassis that can be deployed in any combination of Layer 2, Layer 3, DCI, or aggregation applications, thereby reducing Capital Expenditures (CapEx) and Operating Expenses (OpEx), as well as reducing the time required to develop and deploy new services.
Cisco ASR 9000 Series Carrier Ethernet applications include business services such as Layer 2 and Layer 3 VPN (L2VPN and L3VPN, mobile backhaul transport networks, and Broadband Network Gateway (BNG). Features supported include Ethernet Services; L2VPN; IPv4, IPv6, and L3VPN; Layer 2 and Layer 3 multicast; Synchronous Ethernet (SyncE), Ethernet Operations, Administration, and Maintenance (EOAM) and MPLS OAM, Layer 2 and Layer 3 Access Control Lists (ACLs), Hierarchical Quality of Service (HQoS), MPLS Traffic Engineering Fast Reroute (MPLS TE-FRR), Multichassis Link Aggregation (MC-LAG), Integrated Routing and Bridging (IRB) and Cisco Nonstop Forwarding (NSF) and Nonstop Routing (NSR). The System also supports the advanced features including Segment Routing, EVPN, Programmability and Telemetry and other enhancements in the IOS-XR 64 Bit Operating System.
Specifications for Cisco ASR 9901 Router
|
Category |
Part Number or Specification |
|
Chassis |
|
|
Integrated interfaces |
16×1 GE, 24x 1/10 GE, 2×100 GE |
|
Redundancy |
Power supply and Fan redundancy |
|
Power supply part number |
● A9K-1600W-AC
● A9K-1600W-DC
|
|
Physical specifications |
● Height: 3.43 inches (8.7 cm)
● Width: 17.32 inches (44 cm)
● Depth: 23.62 inches (60 cm)
● Weight of chassis: 47.62 lbs (21.6 kg)
● Weight of fully configured (including 2 x power modules & 3x Fan trays) chassis 55.97 lbs (25.4 kg)
|
|
Power inputs |
● Worldwide ranging AC (90-265V; 50-60 Hz)
● Worldwide ranging DC (-40V to -72V)
|
|
Power consumption |
● 850 watts typical, 1100 watts maximum
|
|
Environmental conditions |
● Operating temperature: 41° to 104°F (5° to 40°C)
● Storage temperature: -40 to 167°F (-40 to 75°C)
● Relative humidity: 10 to 85%, noncondensing
● Regulatory compliance
|
|
Environmental Specifications |
|
|
Operating temperature (nominal) |
41 to 104°F (5 to 40°C) |
|
Operating temperature |
23 to 131°F (-5 to 55°C) |
|
Operating humidity (nominal) (relative humidity) |
10 to 85% |
|
Operating humidity |
5 to 90% |
|
Storage temperature |
-40 to 158°F (-40 to 70°C) |
|
Storage (relative humidity) |
5 to 95% |
|
Operating altitude |
0 – 4000 m |
|
Air flow |
Front to Back |
|
Compliance |
|
|
Network Equipment Building Standards (NEBS) |
Cisco ASR 9901 is designed to meet: ● SR-3580: NEBS Criteria Levels (Level 3)
● GR-1089-CORE: NEBS EMC and Safety
● GR-63-CORE: NEBS Physical Protection
● VZ.TPR.9205: Verizon TEEER
|
|
ETSI standards |
Cisco ASR 9901 is designed to meet (qualification in progress): ● EN300 386: Telecommunications Network Equipment (EMC)
● ETSI 300 019 Storage Class 1.1
● ETSI 300 019 Transportation Class 2.3
● ETSI 300 019 Stationary Use Class 3.1
● EN55022: Information Technology Equipment (Emissions)
● EN55024: Information Technology Equipment (Immunity)
● EN50082-1/EN-61000-6-1: Generic Immunity Standard
|
|
EMC standards |
Cisco ASR 9901 is designed to meet: ● FCC Class A
● ICES 003 Class A
● AS/NZS 3548 Class A
● CISPR 22 (EN55022) Class A
● VCCI Class A
● BSMI Class A
● IEC/EN 61000-3-2: Power Line Harmonics
● IEC/EN 61000-3-3: Voltage Fluctuations and Flicker
● EN 50121-4: Railway EMC
|
|
Immunity |
Cisco ASR 9901 is designed to meet: ● IEC/EN-61000-4-2: Electrostatic Discharge Immunity (8kV Contact, 15kV Air)
● IEC/EN-61000-4-3: Radiated Immunity (10V/m)
● IEC/EN-61000-4-4: Electrical Fast Transient Immunity (2kV Power, 1kV Signal)
● IEC/EN-61000-4-5: Surge AC Port (4kV CM, 2kV DM)
● IEC/EN-61000-4-5: Signal Ports (1kV)
● IEC/EN-61000-4-5: Surge DC Port (1kV)
● IEC/EN-61000-4-6: Immunity to Conducted Disturbances (10Vrms)
● IEC/EN-61000-4-8: Power Frequency Magnetic Field Immunity (30A/m)
● IEC/EN-61000-4-11: Voltage DIPS, Short Interruptions, and Voltage Variations
● EN 50121-4: Railway EMC
|
|
Safety |
Cisco ASR 9901 is designed to meet: ● UL/CSA/IEC/EN 60950-1
● IEC/EN 60825 Laser Safety
● ACA TS001
● AS/NZS 60950
● FDA: Code of Federal Regulations Laser Safety
|
The ASR 9901 Compact Router is available to order through the Flexible Consumption Model (FCM) and Traditional Business Model.
The Flexible Consumption Model offers a built-in “pay-as-you-grow” structure that lowers initial start-up costs with the ability to add more capacity overtime as needed. Software subscription provides feature upgrades and helps defer the payment of software value for the initial purchase.
Ordering information for the ASR 9901 Router with the Flexible Consumption Model
|
Part number |
Feature description |
|
ASR-9901-FC |
ASR 9901 456G Flexible Consumption Chassis |
|
A9K-1600W-AC |
ASR 9900 Series 1600W AC Power Supply for ASR-9901 |
|
A9K-1600W-DC |
ASR 9900 Series 1600W DC Power Supply for ASR-9901 |
|
ASR-9901-FAN |
ASR 9901 Fan Tray |
|
ASR-9901-2P-KIT |
ASR 9901 2 Post Mounting Kit for 19 & 23 in Rack |
|
ASR-9901-4P-KIT |
ASR 9901 4 Post Mounting Kit for 19 & 23 in Rack |
|
S-A9K-LI-LIC-FC |
ASR 9K Smart License Lawful Intercept – Flexible Consumption Model |
|
S-A9K-BNG-8K-FC |
ASR 9K FCM Smart License for 8,000 BNG Subscribers |
|
S-A9K-BNG-ADV-FC |
ASR 9K FCM Smart License for BNG Advance features |
|
ESS-ED-100G-RTU1 |
Edge Essentials Software RTU License per 100G |
|
ADV-ED-100G-RTU1 |
Edge Advantage w/o Essentials Software RTU License per 100G |
|
ADN-ED-100G-RTU1 |
Edge Advantage w/ Essentials Software RTU License per 100G |
|
ESS-ED-100G-SIA5 |
Edge Essentials SIA per 100G 60-120 months |
|
ESS-ED-100G-SIA3 |
Edge Essentials SIA per 100G 36-59 months |
|
ADV-ED-100G-SIA5 |
Edge Advantage w/o Essentials SIA per 100G for 60-120 months |
|
ADV-ED-100G-SIA3 |
Edge Advantage w/o Essentials SIA per 100G for 36-59 months |
|
ADN-ED-100G-SIA5 |
Edge Advantage w/ Essentials SIA per 100G for 60-120 months |
|
ADN-ED-100G-SIA3 |
Edge Advantage w/ Essentials SIA per 100G for 36-59 months |
provides hardware ordering information for the ASR 9901 Router with the Traditional Business Model.
|
Part number |
Feature description |
|
ASR-9901 |
ASR 9901 Chassis |
|
ASR-9901-120G |
ASR 9901 Chassis Pay-As-You-Grow 120G Base HW PID |
|
ASR-9901-256G |
ASR 9901 Chassis Pay-As-You-Grow Base HW PID |
|
A9K-1600W-AC |
ASR 9900 Series 1600W AC Power Supply for ASR-9901 |
|
A9K-1600W-DC |
ASR 9900 Series 1600W DC Power Supply for ASR-9901 |
|
ASR-9901-FAN |
ASR 9901 Fan Tray |
|
ASR-9901-2P-KIT |
ASR 9901 2 Post Mounting Kit for 19 & 23 in Rack |
|
ASR-9901-4P-KIT |
ASR 9901 4 Post Mounting Kit for 19 & 23 in Rack |
|
A9K9901-UP120-256G |
ASR 9901 120 – 256 Upgrade License |
|
A9K9901-UP256-456G |
ASR 9901 256 – 456 Upgrade License |
Feature license information for the ASR 9901 Router with the Traditional Business Model
|
Part number |
Feature description |
|
S-A9K-9901-VRF-LC |
ASR 9K Smart License I-VRF for 9901 System, up to 8 VRFs |
|
S-A9K-9901-AIP-LC |
ASR 9K Smart License L3 VPN for NON PAYG 9901 System |
|
S-A9K-9901-120AIP |
ASR 9K Smart License L3 VPN for 120G PAYG 9901 System |
|
S-A9K-9901-256AIP |
ASR 9K Smart License L3 VPN for NON PAYG 9901 System |
|
S-A9K-LI-LIC |
ASR 9K Smart License Lawful Intercept |
|
S-A9K-MOBILE-LIC |
ASR 9K Smart License Advanced Mobile for System |
|
S-A9K-TUNNEL-ENT |
ASR 9K Smart License RTU License for Tunnel Protocols |
|
S-A9K-SESSION-128K |
ASR 9K Smart License 128000 End User Sessions |
|
S-A9K-BNG-LIC-8K |
ASR 9K Smart License BNG 8K Sessions |
|
S-A9K-BNG-ADV-8K |
ASR 9K Smart License BNG license for Advance Features |
|
S-A9K-NVSAT1-LIC |
NV Host License for 1 nV Client |
|
S-A9K-NVSAT5-LIC |
NV Host License for Up to 5 nV Clients |
|
S-A9K-NVSAT20-LIC |
NV Host License for Up to 20 nV Clients |
