ASR 9912 Fan Tray
$0.00
Condition: NOB
RMA Warranty
Description
Product overview
The Cisco® ASR 9000 Series Aggregation Services Routers (ASR 9000 Series) represent an exciting new paradigm in edge and core routing, with exceptional scalability, carrier-class reliability, environmentally conscious design, incredible flexibility, and an attractive price-to-performance benchmark. The Cisco ASR 9000 Series has a wide product portfolio, ranging from the Cisco ASR 9001 (2 Rack Units [2RU]) to the Cisco ASR 9922 (44RU), with each system designed to provide true carrier-class reliability using the Cisco IOS® XR operating system, comprehensive system redundancy, and a full complement of network resiliency schemes. Finally, the Cisco ASR 9000 Series is designed to simplify and enhance the operational and deployment aspects of service-delivery networks.
Cisco ASR 9912 and ASR 9922
|
Specification |
Model |
|
|
Cisco ASR 9912 |
Cisco ASR 9922 |
|
|
Categories |
||
|
Physical specifications |
Height: 52.5 in. (1333.5 mm) (30 RU) Width: 17.60 in. (447.04 mm) Depth: ● With door: 30.03 in. (762.76 mm)
● Without doors: 29.25 in. (742.95mm)
Weight: ● 231.25 lb (105.11 kg) (3 PEMs and chassis)
● 389.55 lb (177.07 kg) (3 PEMs, 2 Fan Trays, 2 RP2, and 5 Fabric Card 2)
|
Height: 77 in. (1955.4 mm) (44 RU) Width: 17.60 in. (447.04 mm) Depth: ● With doors: 30.68 in. (779.27 mm)
● Without doors: 30.19 in. (766.82 mm)
Weight: ● 413 lb (187.73 kg) (4 PEM and chassis)
● 639.5 lb (290.7 kg) (2 RP2, 7 Fabric Cards 2, 4 Fan Trays, and 4 PEMs)
|
|
Slot orientation |
Vertical |
Vertical |
|
Cisco ASR 9000 Series RSP |
RSPs segregated into route processor and fabric cards |
RSPs segregated into route processor and fabric cards |
|
Route processor |
Dual redundant route processors in 2 slots |
Dual redundant route processors in 2 slots |
|
Fabric cards |
6 + 1 redundant fabric cards |
6 + 1 redundant fabric cards |
|
Cisco ASR 9000 Series line cards |
10 line-card slots |
20 line-card slots |
|
“Commons” components |
2 route processors 7 fabric cards 2 fan trays 3 PEMs (either DC or AC) 1 center fan filter, 2 side fan filters |
2 route processors 7 fabric cards 4 fan trays 4 PEMs (either DC or AC) 1 center fan filter, 2 side fan filters |
|
Reliability and availability |
Fabric redundancy Fan redundancy Feed redundancy Power-supply redundancy Route-processor redundancy Software redundancy |
Fabric redundancy Fan redundancy Feed redundancy Power-supply redundancy Route-processor redundancy Software redundancy |
|
Rack mounting |
19-in. 21- and 23-in. adapters available |
19-in. 21- and 23-in. adapters available |
|
Cabinet mounting |
Yes Note: Doors not recommended in enclosed cabinets |
Yes Note: Doors not recommended in enclosed cabinets |
|
Wall mounting |
No |
No |
|
Airflow |
Front-to-back |
Front-to-back |
|
Performance |
||
|
Fabric |
Seven switch fabric card slots: ● Support for 6 + 1 redundancy
● Operate in active/active nonblocking mode
● Built-in service-intelligence and traffic-prioritization capability
|
Seven switch fabric card slots: ● Supports 6 + 1 redundancy
● Operate in active/active nonblocking mode
● Built-in service-intelligence and traffic-prioritization capability
|
|
Thermal |
Two fan trays: ● 12 high-efficiency fans per tray
● Variable-speed fans for optimal thermal performance
● No single point of failure
|
Four fan trays: ● 12 high-efficiency fans per tray
● Variable-speed fans for optimal thermal performance
● No single point of failure
|
|
Power |
||
|
Modularity |
Pay-as-you-grow power for future scalability, available in AC and DC Multiple power module types: ● 6 kW and 3 kW AC power modules
● 4.4 kW and 2.1 kW DC power modules
Note: Mixing of AC and DC modules is not supported |
Pay-as-you-grow power for future scalability, available in AC and DC Multiple power module types: ● 6 kW and 3 kW AC power modules
● 4.4 kW and 2.1 kW DC power modules
Note: Mixing of AC and DC modules is not supported |
|
Redundancy |
● AC: N+N redundancy
● DC: N+1 redundancy
● Power module redundancy
● A/B Feed redundancy
● PEM redundancy
|
● AC: N+N redundancy
● DC: N+1 redundancy
● Power module redundancy
● A/B Feed redundancy
● PEM redundancy
|
|
Power zones |
No power zone restrictions Fully load-sharing power infrastructure |
No power zone restrictions Fully load-sharing power infrastructure |
|
Power input |
Worldwide ranging AC (200-240V; 50-60 Hz; 16A maximum) Worldwide ranging DC (-40 to -72V; 50A nominal, 60A maximum) |
Worldwide ranging AC (200-240V; 50-60 Hz; 16A maximum) Worldwide ranging DC (-40 to -72V; 50A nominal, 60A maximum) |
|
Power module airflow |
Front-to-back |
Front-to-back |
|
Environmental Specifications (All Entries Applicable to Cisco ASR 9912 and ASR 9922) |
||
|
Operating temperature (nominal) |
41 to 104°F (5 to 40°C) |
|
|
Operating temperature (short-term) |
23 to 131°F (-5 to 55°C) |
|
|
Operating humidity (nominal) (relative humidity) |
5 to 90% |
|
|
Storage temperature |
-40 to 158°F (-40 to 70°C) |
|
|
Storage (relative humidity) |
5 to 93% |
|
|
Operating altitude |
-60 to 4000m (up to 2000m conforms to IEC/EN/UL/CSA 60950 requirements) |
|
|
Regulatory Compliance (All Entries Applicable to Cisco ASR 9912 and ASR 9922) |
||
|
Network Equipment Building Standards (NEBS) |
Cisco ASR 9912 and ASR 9922 Routers are designed to meet: ● SR-3580: NEBS Criteria Levels (Level 3)
● GR-1089-CORE: NEBS EMC and Safety
● GR-63-CORE: NEBS Physical Protection
● VZ.TPR.9205: Verizon TEEER
|
|
|
ETSI standards |
Cisco ASR 9912 and ASR 9922 Routers are designed to meet: ● EN300 386: Telecommunications Network Equipment (EMC)
● ETSI 300 019 Storage Class 1.1
● ETSI 300 019 Transportation Class 2.3
● ETSI 300 019 Stationary Use Class 3.1
|
|
|
EMC standards emission |
Cisco ASR 9912 and ASR 9922 Routers are designed to meet: ● FCC Class 47CFR15 A
● ICES 003 Class A
● AS/NZS CISRP22 Class A
● CISPR 22 (EN55022) Class A
● VCCI Class A
● BSMI Class A
● IEC/EN 61000-3-12: Power Line Harmonics
● IEC/EN 61000-3-11: Voltage Fluctuations and Flicker
● EN55022: Information Technology Equipment (Emissions)
● EN 50121-4: Railway EMC
|
|
|
EMC standards immunity |
Cisco ASR 9912 and ASR 9922 Routers are designed to meet: ● IEC/EN-61000-4-2: Electrostatic Discharge Immunity (8kV Contact, 15kV Air)
● IEC/EN-61000-4-3: Radiated Immunity (10V/m)
● IEC/EN-61000-4-4: Electrical Fast Transient Immunity (2kV Power, 1kV Signal)
● IEC/EN-61000-4-5: Surge AC Port (4kV CM, 2kV DM)
● IEC/EN-61000-4-5: Signal Surge Ports (1kV)
● IEC/EN-61000-4-5: Surge DC Port (1kV CM, 1kV DM)
● IEC/EN-61000-4-6: Immunity to Conducted Disturbances (10Vrms)
● IEC/EN-61000-4-8: Power Frequency Magnetic Field Immunity (30A/m)
● IEC/EN-61000-4-11: Voltage DIPS, Short Interruptions, and Voltage Variations
● EN55024: Information Technology Equipment (Immunity)
● EN50082-1/EN-61000-6-1: Generic Immunity Standard
● EN 50121-4: Railway EMC
|
|
|
Safety |
Cisco ASR 9912 and ASR 9922 Routers are designed to meet: ● UL/CSA/IEC/EN 60950-1
● IEC/EN 60825 Laser Safety
● ACA TS001
● AS/NZS 60950
● FDA Code of Federal Regulations Laser Safety
|
|
