Overview:
The FortiGate 401F Series NGFW combines AI-powered security and machine learning to deliver Threat Protection at any scale. Get deeper visibility into your network and see applications, users, and devices before they become threats.
Powered by a rich set of AI/ML security capabilities that extend into an integrated security fabric platform, the FortiGate 401F Series delivers secure networking that is broad, deep, and automated. Secure your network end to end with advanced edge protection that includes web, content, and device security, while network segmentation and secure SD-WAN reduce complexity and risk in hybrid IT networks.
Universal ZTNA automatically controls, verifies, and facilitates user access to applications, reducing lateral threats by providing access only to validated users. Ultra-fast Threat Protection and SSL Inspection provides security at the edge you can see without impacting performance.
Use Cases
Next Generation Firewall (NGFW)
- FortiGuard Labs’ suite of AI-powered Security Services—natively integrated with your NGFW—secures web, content, and devices and protects networks from ransomware and sophisticated cyberattacks
- Real-time SSL inspection (including TLS 1.3) provides full visibility into users, devices, and applications across the attack surface
- Fortinet’s patented SPU (Security Processing Unit) technology provides industry-leading high-performance protection
Secure SD-WAN
- FortiGate WAN Edge powered by one OS and unified security and management framework and systems transforms and secures WANs
- Delivers superior quality of experience and effective security posture for work-from-any where models, SD-Branch, and cloud-first WAN use cases
- Achieve operational efficiencies at any scale through automation, deep analytics, and self-healing
Universal ZTNA
- Control access to applications no matter where the user is and no matter where the application is hosted for universal application of access policies
- Provide extensive authentications, checks, and enforce policy prior to granting application access—every time
- Agent-based access with FortiClient or agentless access via proxy portal for guest or BYOD
Segmentation
- Dynamic segmentation adapts to any network topology to deliver true end-to-end security—from the branch to the datacenter and across multi-cloud environments
- Ultra-scalable, low latency, VXLAN segmentation bridges physical and virtual domains with Layer 4 firewall rules
- Prevents lateral movement across the network with advanced, coordinated protection from FortiGuard Security Services detects and prevents known, zero-day, and unknown attacks
IPS | NGFW | Threat Protection | Interfaces |
---|---|---|---|
12 Gbps | 10 Gbps | 9 Gbps | Multiple GE RJ45, 10GE SFP+ Slots, GE SFP Slots |
Specifications:
FortiGate 401F | ||
---|---|---|
Interfaces and Modules | ||
Hardware Accelerated GE RJ45 Interfaces | 16 | |
Hardware Accelerated GE SFP Slots | 8 | |
Hardware Accelerated 10GE SFP+ Slots | 4 | |
Hardware Accelerated 10GE SFP+ Ultra Low Latency Slots | 4 | |
GE RJ45 Management Ports | 2 | |
USB Ports | 1 | |
RJ45 Console Port | 1 | |
Onboard Storage | 2x 480 GB SSD | |
Trusted Platform Module (TPM) | Yes | |
Included Transceivers | 2x SFP (SX 1 GE) | |
System Performance — Enterprise Traffic Mix | ||
IPS Throughput | 12 Gbps | |
NGFW Throughput | 10 Gbps | |
Threat Protection Throughput | 9 Gbps | |
System Performance and Capacity | ||
IPv4 Firewall Throughput (1518 / 512 / 64 byte, UDP) |
79.5 / 78.5 / 70 Gbps | |
IPv6 Firewall Throughput (1518 / 512 / 64 byte, UDP) |
79.5 / 78.5 / 70 Gbps | |
Firewall Latency (64 byte, UDP) | 4.19 μs / 2.5 μs | |
Firewall Throughput (Packet per Second) | 105 Mpps | |
Concurrent Sessions (TCP) | 7.8 Million | |
New Sessions/Second (TCP) | 500,000 | |
Firewall Policies | 10,000 | |
IPsec VPN Throughput (512 byte) | 55 Gbps | |
Gateway-to-Gateway IPsec VPN Tunnels | 2,000 | |
Client-to-Gateway IPsec VPN Tunnels | 50,000 | |
SSL-VPN Throughput | 3.6 Gbps | |
Concurrent SSL-VPN Users (Recommended Maximum, Tunnel Mode) |
5,000 | |
SSL Inspection Throughput (IPS, avg. HTTPS) | 8 Gbps | |
SSL Inspection CPS (IPS, avg. HTTPS) | 6,000 | |
SSL Inspection Concurrent Session (IPS, avg. HTTPS) | 800,000 | |
Application Control Throughput (HTTP 64K) | 28 Gbps | |
CAPWAP Throughput (HTTP 64K) | 65 Gbps | |
Virtual Domains (Default / Maximum) | 10 / 10 | |
Maximum Number of FortiSwitches Supported | 72 | |
Maximum Number of FortiAPs (Total / Tunnel) | 512 / 256 | |
Maximum Number of FortiTokens | 5,000 | |
High Availability Configurations | Active-Active, Active-Passive, Clustering | |
Dimensions and Power | ||
Height x Width x Length (inches) | 1.75 x 17.0 x 15.0 | |
Height x Width x Length (mm) | 44.45 x 432 x 380 | |
Weight | 14.33 lbs (6.5 kg) | |
Form Factor | Rack Mount, 1 RU | |
Power Consumption (Average / Maximum) | 161.1 W / 196.9 W | |
Power Source | 100–240V AC, 50/60Hz | |
Current (Maximum) | 6A | |
Heat Dissipation | 671.85 BTU/h | |
Power Supply Efficiency Rating | 80Plus Compliant | |
Redundant Power Supplies (Hot Swappable) | (Default dual AC PSU for 1+1 Redundancy) | |
Operating Environment and Certifications | ||
Operating Temperature | 32–104°F (0–40°C) | |
Storage Temperature | -31–158°F (-35–70°C) | |
Humidity | 5–90% non-condensing | |
Noise Level | LPA 48 dBA / LWA 55 dBA | |
Operating Altitude | Up to 10 000 ft (3048 m) | |
Noise Level | LPA 48 dBA / LWA 55 dBA | |
Airflow | Side and Front to Back | |
Compliance | FCC Part 15 Class A, RCM, VCCI, CE, UL/cUL, CB | |
Certifications | ICSA Labs: Firewall, IPsec, IPS, Antivirus, SSL-VPN, USGv6/IPv6 |
