HPE MSA 1060 12Gb SAS SFF Storage
Condition: NOB
RMA Warranty
Description
Overview
Need a modern, flash-enabled, affordable shared storage array with a limited budget? HPE MSA 1060 storage brings affordable flash storage to even the most sensitive customers. HPE MSA 1060 storage is designed to meet entry-level storage requirements, making it ideal for customers on a limited budget. HPE MSA 1060 storage is one of the lowest-priced entry-level products in the Hewlett Packard Enterprise storage portfolio and features field-proven HPE ProLiant compatibility, making it the platform of choice for smaller IT workloads. The HPE MSA 1060 storage has one of the lowest entry prices in the Hewlett Packard Enterprise storage portfolio and features field-proven HPE ProLiant compatibility, making it the platform of choice for small IT workloads.The HPE MSA 1060 storage features 10GBASE-T iSCSI, Fibre Channel and SAS host interface connectivity, and is available at an entry price point previously unattainable. The MSA 1060 allows users to take advantage of the latest storage technologies while balancing performance and budget.
HPE MSA 1060 Storage
HPE MSA 1060 Storage-Rear View
| 1. | Power Switch | 5. | 12Gb SAS expansion port |
| 2. | Redundant Power and Cooling Module (AC or DC) | 6. | Controller A (Inverted) |
| 3. | Host connection ports (8/16Gb FC, 1/10Gb iSCSI or 12Gb SAS depending on model) | 7. | Controller B |
| 4. | Ethernet management port |
| HPE MSA 1060 Storage | |
| Array | |
| Access Type | Block |
| Form Factor | 2U, SFF |
| Number of controllers per array | 2 |
| Number of host ports per array | 4 |
| FC host connectivity | 8/16Gb |
| iSCSI host connectivity | 1/10Gb |
| SAS host connectivity | 12Gb |
| Cache, per array | |
| Max Read cache per array | 8TB |
| Data (read/write) cache + system memory per array | 24GB |
| Pool Capacity | Two Pools with 1 PB each |
| RAID Levels supported: | RAID 0*,1, 5, 6, 10, MSA-DP+
Notes: *Read Cache Only |
| Enclosures | |
| Expansion Drive Enclosures | 0-3 enclosures |
| LFF/SFF array/enclosure mixing | Supported |
| Maximum number of drives per array enclosure | 24 SFF |
| Maximum number of drives per drive enclosure | 24 SFF or 12 LFF |
| Drive enclosure interface type | 12Gb SAS |
| Drives | |
| Maximum total HDDs per array | 96 SFF / 24SFF + 36 LFF |
| Maximum total SSDs per array | 96 SFF / 24SFF + 36 LFF |
| Max raw capacity per array enclosure | 184.32TB SFF |
| Max raw capacity per drive enclosure | 184.32TB SFF / 240TB LFF |
| Max raw capacity per array | 737.28TB (All SFF)
904.32TB (SFF array + LFF drive enclosures) |
| Drive Capacities | |
| SFF SSDs | 960GB, 1.92TB, 3.84TB, 7.68TB |
| LFF SSD | 1.92TB |
| SFF HDDs | 15K: 900GB
10K: 600GB, 1.2TB, 1.8TB, 2.4TB |
| LFF HDDs | 7.2K: 6TB, 8TB, 10TB, 12TB, 14TB, 16TB, 18TB, 20TB |
| Self-Encrypting SSDs | SFF: 960GB, 1.92TB
LFF: 1.92TB |
| Self-Encrypting HDDs
Notes: Sold in 6 Pack bundles only |
SFF: 900GB, 2.4TB
LFF: 12TB |
| Software Features | |
| Thin Technologies | Thin Provisioning, Space Reclamation, Thin Rebuild |
| Tiering | Performance Tier, Standard Tier, Archive Tier |
| Replication | Snapshots (512), Volume Copy, Remote Snaps |
| Quality of Service | Virtual Tier Affinity |
| Additional Features | |
| Maximum number of volumes per pool | 512 |
| Maximum number of volumes per array | 1024 |
| Maximum number of snapshots (included with array) | 64 |
| Maximum number of snapshots (with Advanced Data Services License) | 512 |
| Maximum number of hosts | 512 |
| Maximum number of initiators | 1024 |
| Customer self-installable | Yes |
| Customer self-repairable | Yes |
| Customer self-upgradeable | Yes |
| Health Check analytics | Yes |
| Energy Star Certified | Yes |
| MSA 1060 | |
| Power Requirements | |
| Input Power Requirements (typical-running I/O)
SFF/LFF arrays |
120VAC 3.07A, 293-361 W
220VAC 1.58A, 289-352W |
| Max Input Power | 100-240 VAC, 50/60 Hz., 4.38-2.17A; 48-60 VDC 10.4A/8.3A |
| Heat Dissipation | 1766 BTU/hr |
| Temperature and Humidity Ranges | |
| Operating Temperature | ASHRAE A3 5°C to 40°C, -12°C DP & 8 to 24°C DP
(Derate maximum allowable dry-bulb temperature 1°C/175m above 900m) |
| Shipping Temperature | -40°F to 158°F (-40°C to 70°C) |
| Operating Humidity | Up to 85% RH |
| Non-Operating Humidity | Up to 90% RH @ 30°C |
| Physical | |
| Height | 3.5 in (8.9 cm) |
| Depth (Back of chassis ear to controller latch) | 20.0 in (50.8 cm) |
| Depth (Front of chassis ear to back of cable bend) | 26.4 in (66.9 cm) |
| Width (Chassis only) | 17.5 in (44.5 cm) |
| Width (Chassis with bezel ear caps) | 19.0 in (48.3 cm) |
| Weight LFF Enclosure | |
| Chassis empty | 11 lb (5 kg) |
| Controller enclosure (fully populated with FRUs and disks) | 71 lb (32 kg) |
| Expansion enclosure (fully populated with FRUs and disks) | 62 lb (28 kg) |
| Weight SFF Enclosure | |
| Chassis empty | 11 lb (5 kg) |
| Controller enclosure (fully populated with FRUs and disks) | 66 lb (30 kg) |
| Expansion enclosure (fully populated with FRUs and disks) | 55 lb (25 kg) |
Configuration Information
| Description | SKU | |
| MSA 1060 Storage Systems | ||
| HPE MSA 1060 16Gb Fibre Channel SFF Storage | R0Q85B | |
| HPE MSA 1060 10GBASE-T iSCSI SFF Storage | R0Q86B | |
| HPE MSA 1060 12Gb SAS SFF Storage | R0Q87B | |
