QUANTUM SPARK 6600

Description

Compare the 6600 Firewall Models

The Quantum 6600 is available in a base or plus model for one, two or three years with all of the security features available. The affordable Plus package is a base system plus 4x 10 GbE SFP+ fiber ports with SR transceivers, 2x AC power supplies, Lights-out Management and 16 GB of memory for high connection capacity

SPECIFICATIONS

Performance

Enterprise Test Conditions
Threat Prevention1 (Gbps) 3.7
NGFW2 (Gbps) 5.5
IPS (Gbps) 10.14
Firewall (Gbps) 18

RFC 3511, 2544, 2647, 1242 Performance (Lab)
Firewall 1518B UDP (Gbps) 32
VPN AES-128 (Gbps) 4.9
Connections/sec 116000
Concurrent connections 2/4/8M

Additional Features

Highlights

• 1x CPUs,4 physical cores
• 1x 240 GB SSD storage
• 1 AC or DC power supply（2xPlus）
• 8, 16 and 32 GB memory options
• Lights-Out-Management (included in Plus)
• Virtual Systems (Base/Plus/max mem): 10/20/20

Network Expansion Slot Options (1 of 1 slots open)

• 8x 10/100/1000Base-T RJ45 port card, up to 18 ports
• 4x 1000Base-F SFP port card, up to 4 ports
•4x 10GBase-F SFP+ port card, up to 4 ports
Content Security

First Time Prevention Capabilities
• CPU-level, OS-level and static file analysis
• File disarm and reconstruction via Threat Extraction
• Average emulation time for unknown files that require full
sandbox evaluation is under 100 seconds
• Maximal file size for Emulation is 100 MB
• Emulation OS Support: Windows XP, 7, 8.1, 10

Applications

• Use 10,000+ pre-defined or customize your own applications
• Accept, prevent, schedule, and apply traffic-shaping

Data Loss Prevention

• Classify 700+ pre-defined data types
• End user and data owner incident handling

Content Security (continued)
Dynamic User-based Policy
• Integrates with Microsoft AD, LDAP, RADIUS, Cisco pxGrid,
Terminal Servers and with 3rd parties via a Web API
• Enforce consistent policy for local and remote users on Windows,
macOS, Linux, Android and Apple iOS platforms
Network
Network Connectivity
• Integrated SD-WAN network optimization and resilience
• Total physical and virtual (VLAN) interfaces per appliance:
1024/4096 (single gateway/with virtual systems)
• 802.3ad passive and active link aggregation
• Layer 2 (transparent) and Layer 3 (routing) mode
High Availability
• Active/Active L2, Active/Passive L2 and L3
• Session failover for routing change, device and link failure
• ClusterXL or VRRP
IPv6
• NAT66, NAT64, NAT46
• CoreXL, SecureXL, HA with VRRPv3
Unicast and Multicast Routing (see SK98226)
• OSPFv2 and v3, BGP, RIP
• Static routes, Multicast routes
• Policy-based routing
• PIM-SM, PIM-SSM, PIM-DM, IGMP v2, and v3

Physical
Power Requirements

• Power Supply rating: 300W
• AC power input: 100 to 240V (50-60Hz)
• Power consumption avg/max: 84W/147W
• Maximum thermal output: 501.6 BTU/hr.

Dimensions

• Enclosure: 1RU
• Dimensions (WxDxH): 17.2 x 20 x 1.73 in.(438x508x44mm)
• Weight (Base/Plus): 16.5/17.4 lbs. (7.5/7.9 kg)

Environmental Conditions

• Operating: 0° to 40°C, humidity 5 to 95%
• Storage: –20° to 70°C, humidity 5 to 95%

Certifications

• Safety: UL, CB, CE, TUV GS
• Emissions: FCC, CE, VCCI, RCM/C-Tick
• Environmental: RoHS, WEEE, REACH1, ISO14001
