RG S2915 10GT2MS P L F
RG S2915 10GT2MS P L O1
RG S2915 10GT2MS P L O2
RG S2915 10GT2MS P L R

8 x GE PoE+ Ports, 2 x 2.5GE SFP Ports, 125 W

Condition: NOB

RMA Warranty

support team Girl Avatar

Expert Consultant Support

Solution Support ,More Discount.
Live Chat   |   Email
7*24h Online
Global Discount

Description

Offices, hotels, retail stores, factories, and schools
Highlight Features
  • 2.5GE uplinks, overcoming GE limitations, supporting diverse access types, and enabling integration into 10GE networks
  • Unique CPU protection policy, ensuring stability of the switch and nonstop services
  • RLDP used to provide smooth network connections
  • 10 kV surge protection for ports and high reliability
  • Compliance with standard protocols and application in various scenarios
  • Ease of use through Ruijie Cloud for management and remote O&M

Hardware Specifications

Hardware Specifications RG-S2915-48GT4MS-L RG-S2915-24GT4MS-L RG-S2915-24GT4MS-P-L RG-S2915-10GT2MS-P-L
Interface Specifications
Fixed Service Ports 48 × 10/100/1000Base-T Ethernet ports with auto-negotiation, 4 × 2.5GE/1GE SFP ports 24 × 10/100/1000Base-T Ethernet ports with auto-negotiation, 4 × 2.5GE/1GE SFP ports 24 ×

10/100/1000Base-T Ethernet ports with auto-negotiation,

4 × 2.5G/1GE SFP ports

 10 × 10/100/1000Base-T Ethernet ports with auto-negotiation,

2 × 2.5GE/1GE SFP ports
Power modules 1 fixed power module 1 fixed power module 1 fixed power module 1 fixed power module
Fans modules 2 fixed fans 0 2 fixed fans 1 fixed fans
Fixed management ports 1 × RJ45 Console, 1 × USB port 1 × RJ45 Console, 1 × USB port 1 × RJ45 Console, 1 × USB port 1 × RJ45 Console, 1 × USB port
System Specifications
Packet forwarding rate 87 Mpps 51 Mpps 51 Mpps 22.5 Mpps
Switching capacity 116Gbps 68Gbps 68Gbps 30Gbps
MAC Table Capacity 16,000 16,000 16,000 16,000
ARP table 512
Routing Table Size (IPv4/IPv6) 64
ACL entries 500
Dimensions and Weight
Dimensions (W x D x H) 440 mm × 220 mm × 43.5 mm (17.32 in × 8.66 in × 1.71 in), 1 RU 440 mm × 220 mm × 43.5 mm (17.32 in × 8.66 in × 1.71 in), 1 RU 440 mm × 292 mm × 43.6 mm (17.32 in × 11.50 in × 1.72 in), 1 RU 297 mm × 170 mm × 44.5 mm (11.69 in × 6.69 in × 1.75 in), 1 RU
Weight 2.8 kg (6.17 lbs) 2.5 kg (5.51 lbs) 2.8 kg (6.17 lbs) 2.5 kg (5.51 lbs)
CPU and Storage
CPU Built-in CPU, single-core processor, with the clock speed of 1.2 GHz
Flash Memory 64 MB
SDRAM 512 MB
Data packet buffer  512 KB
Power and Consumption
Maximum power consumption < 30 W < 15.6 W < 33 W (non-PoE)

< 403 W (PoE full load)

 < 16 W (non-PoE)

< 141 W (PoE full load)
Rated input voltage 100 V AC to 240 V AC, 50 Hz to 60 Hz 100 V AC to 240 V AC, 50 Hz to 60 Hz 100 V AC to 240 V AC, 50 Hz to 60 Hz 100 V AC to 240 V AC, 50 Hz to 60 Hz
Maximum input voltage 90 V AC to 264 V AC, 50 Hz to 60 Hz 90 V AC to 264 V AC, 50 Hz to 60 Hz 90 V AC to 264 V AC, 50 Hz to 60 Hz 90 V AC to 264 V AC, 50 Hz to 60 Hz
Environment and Reliability
MTBF >200K >200K >200K >200K
Operating Temperature 0°C to 45°C (32°F to 113°F)
Storage Temperature -40°C to +70°C (-40°F to +158°F)
Operating Humidity 10% to 90% RH (non-condensing)
Storage Humidity 5% to 95% RH (non-condensing)
Operating noise ≤ 37 dB Fanless ≤ 39 dB ≤ 37 dB
Interface surge protection Power port: 6 kV/2 kV

Telecom port: 10 kV

 Power port: 6 kV/2 kV

Telecom port: 10 kV

 Power port: 6 kV/2 kV

Telecom port: 10 kV

 Power port: 6 kV/2 kV

Telecom port: 10 kV

Software Specifications

Feature Description
Ethernet switching Jumbo frame (maximum length: 9216 bytes)
802.3az EEE
IEEE 802.1Q (4,094 VLANs)
Voice VLAN
Port based VLAN
Basic QinQ

Selective QinQ
STP (IEEE 802.1.d), RSTP (IEEE 802.1w), MSTP (IEEE 802.1s)
ERPS (G.8032)
LLDP/LLDP-MED
LACP (IEEE 802.3ad)
IP service ARP
DHCP client, DHCP relay, and DHCP server
DHCP snooping
DNS
IP routing Static routing
RIP, RIPng
OSPFv2
ACL and QoS Standard IP ACLs

Extended IP ACLs

Extended MAC ACLs

Expert-level ACLs

ACL 80

IPv6 ACL
ACL redirection
Port traffic rate limiting
802.1p, DSCP, IP precedence traffic prioritization (IEEE 802.1p) for real-time classification
Congestion management: RR, SP, WRR, DRR, WFQ, SP+WRR, SP+DRR, and SP+WFQ
Congestion avoidance: tail drop
Eight priority queues per interface
Security RADIUS and TACACS+
Port-based and MAC-based 802.1x authentication
Web authentication
HTTPS
SSHv1, SSHv2
IGMP V1,V2 snooping
IP Source Guard
CPP and NFPP
Reliability RLDP
Hot swapping of power modules and cables
Temperature Monitoring

Temperature Alarm

Overtemperature Protection
NMS and maintenance RSPAN
sFlow
NTP
TFTP client
SNMP v1/v2c/v3
CLI (telnet/console), syslog/debug, Web, MACC public cloud
CWMP (TR-069) standard protocol
gRPC
PoE IEEE 802.3af and 802.3at

Uninterruptible power supply upon hot start

Port priority
Order Information
Model Description
RG-S2915-48GT4MS-L 48 × 10/100/1000Base-T copper ports with auto-negotiation, 4 × 1GE/2.5GE SFP ports, fixed single AC power supply
RG-S2915-24GT4MS-L 24 × 10/100/1000Base-T copper ports with auto-negotiation, 4 × 1GE/2.5GE SFP ports, fixed single AC power supply
RG-S2915-24GT4MS-P-L 24 × 10/100/1000Base-T copper ports with auto-negotiation, 4 × 1GE/2.5GE SFP ports, fixed single AC power supply, PoE/PoE+ power supply, 370 W PoE power supply
RG-S2915-10GT2MS-P-L 10 × 10/100/1000Base-T copper ports with auto-negotiation, 2 × 1GE/2.5GE SFP ports, fixed single AC power supply, PoE/PoE+ power supply, 125 W PoE power supply
2.5G-SFP-LX03-SM1310-BIDI-I SFP 2.5G BIDI transceiver-TX1310/RX1550, 3 km, LC
2.5G-SFP-LX03-SM1550-BIDI-I SFP 2.5G BIDI transceiver-TX1550/RX1310, 3 km, LC
MINI-GBIC-SX-MM850 1000BASE-SX, SFP transceiver, SM (850 nm, 500 m, LC).
MINI-GBIC-LX-SM1310 1000BASE-LX, SFP transceiver, SM (1310 nm, 10 km, LC)
MINI-GBIC-LH40-SM1310 1000BASE-LH, SFP transceiver, SM (1310 nm, 40 km, LC)
MINI-GBIC-ZX80-SM1550 1000BASE-ZX80, SFP transceiver, SM (1550 nm, 80 km, LC)
GE-SFP-LX20-SM1310-BIDI SFP BIDI Transceiver-TX1310/RX1550, 20 km, LC
GE-SFP-LX20-SM1550-BIDI SFP BIDI Transceiver-TX1550/RX1310, 20 km, LC
GE-SFP-LH40-SM1310-BIDI SFP BIDI Transceiver-TX1310/RX1550, 40 km, LC
GE-SFP-LH40-SM1550-BIDI SFP BIDI Transceiver-TX1550/RX1310, 40 km, LC
Mini-GBIC-GT 1000BASE-TX, SFP transceiver (100 m)
