48 x 10/100/1000Base-T (PoE+) ports, 4 x GE SFP ports
Condition: NOB
RMA Warranty
Description
The S1700 series switches are next-generation energy-saving Ethernet access switches. They provide easy installation and maintenance methods and various service features to help users build secure, reliable, and high-performance networks. The S1700 series switches can be widely used in Ethernet access scenarios such as small- and medium-sized enterprises, Internet cafes, hotels, and schools.
| Model | S1730S-S48P4S-A |
| Forwarding Performance | 77.38 mpps |
| Switching Capacity? | 216 Gbit/s |
| Fixed Ports | 48 x 10/100/1000Base-T (PoE+) ports, 4 x GE SFP ports |
| Power Supply | Pluggable 1000W AC power module |
S1730S-S48P4S-A Specification |
|
| Forwarding Performance | 77.38 mpps |
| Switching Capacity | 216 Gbit/s |
| Fixed Ports | 48 x 10/100/1000Base-T (PoE+) ports, 4 x GE SFP ports |
| Power Supply | Pluggable 1000W AC power module |
| Dimension (H × W × D) | 43.6mm × 442mm × 220mm |
| Chassis Height | 1U |
| Rated Voltage Range | – 100V AC to 130V AC,200V AC to 240V AC, 50/60 Hz
– High-voltage DC input: 240V DC |
| Maximum Voltage Range | – 90V AC to 290V AC, 45 Hz to 65 Hz
– High-voltage DC input: 190V DC to 290V DC |
| Maximum Power Consumption | Without PoE: 75W
100% PoE loads: 911W (PoE: 874W) |
| Operating Temperature | 5°C to +50°C (23°F to 122°F) at an altitude of 0-1800m (0-5906 ft.) |
| Storage Temperature | -40°C to +70°C (-40°F to +158°F) |
