Cisco MDS 9148S 16G Multilayer Fabric Switch with 48 enabled ports
Condition: NOB
RMA Warranty
The Cisco MDS 9148S 16G Multilayer Fabric Switch is the next generation of Cisco’s MDS 9100 series switches, offering high reliability, flexibility, and cost-effectiveness. This 1RU switch is compact yet powerful, with scalability ranging from 12 to 48 line-rate 16 Gbps Fibre Channel ports.
The Cisco MDS 9148S is an ideal solution for various storage environments, including standalone SANs in small departmental storage setups, top-of-the-rack switches in medium-sized redundant fabrics, and edge switches in enterprise data center core-edge topologies.
Powered by Cisco NX-OS and Cisco Prime Data Center Network Manager (DCNM) software, the Cisco MDS 9148S provides advanced storage networking features and functions. It offers ease of management and compatibility with the entire Cisco MDS 9000 Family portfolio, ensuring reliable end-to-end connectivity.
With its combination of high performance, flexibility, and cost-effectiveness, the Cisco MDS 9148S is suitable for a wide range of storage networking requirements in various environments.
The Cisco MDS 9148S offers high performance and flexibility at a low cost. It supports up to 48 autosensing Fibre Channel ports with speeds of 2, 4, 8, and 16 Gbps. Each port has dedicated 16 Gbps bandwidth. The base switch model comes with 12 ports enabled and can be upgraded with the On-Demand Port Activation license to support configurations of 24, 36, or 48 enabled ports. This switch is the first generation of NVMe-ready Fibre Channel 1RU switches, making it suitable for host connectivity in N-Port virtualization (NPV) or N-Port ID Virtualization (NPIV) core deployments.
For mission-critical deployments, the Cisco MDS 9148S offers In-Service Software Upgrades (ISSU), allowing software upgrades while Fibre Channel ports are carrying traffic. It includes dual redundant hot-swappable power supplies and fan trays for high availability. PortChannels and F-port channeling provide resiliency for Inter-Switch Link (ISL) and uplinks when operating in NPV mode. It also features hardware-based slow port detection and recovery for enhanced performance and monitoring.
Storage management is simplified with built-in network management and SAN plug-and-play capabilities. The switch can be managed through a Command-Line Interface (CLI) or Cisco Prime DCNM for SAN Essentials Edition. Cisco DCNM offers task-based wizards for simplified management of single or multiple switches and fabrics. It supports PowerOn Auto Provisioning (POAP) for automated software image upgrades and configuration file installation. Intelligent diagnostics, protocol decoding, network analysis tools, and Cisco Call Home are included for reliable performance, faster problem resolution, and reduced service costs.
The Cisco MDS 9148S provides intelligent network services and advanced traffic management. It uses virtual SAN (VSAN) technology for isolated environments within a physical fabric and offers access control lists (ACLs) for intelligent frame processing. Optional features such as fabricwide Quality of Service (QoS) and Inter-VSAN Routing (IVR) are available in the Cisco MDS 9000 Family Enterprise Package. QoS prioritizes application data traffic, while IVR facilitates resource sharing across VSANs without compromising scalability, reliability, availability, and network security.
A comprehensive network security framework is offered with the Cisco MDS 9000 Family Enterprise Package. It includes fabricwide, per-VSAN role-based Authentication, Authorization, and Accounting (AAA) services using various protocols. Security features include fabric isolation, packet inspection, host-to-switch, and switch-to-switch authentication, SFTP, SSHv2, SNMPv3 with AES encryption, control-plane security, hardware-enforced zoning, broadcast zones, and FIPS 140-2 compliance.
Overall, the Cisco MDS 9148S is a high-performance, flexible, and cost-effective solution with advanced features for reliable and secure storage networking.
|
Feature |
Benefit |
|
Common software across all platforms |
Reduce Total Cost of Ownership (TCO) by using Cisco NX-OS and Cisco Prime DCNM for consistent provisioning, management, and diagnostic capabilities across the fabric. |
|
PowerOn Auto Provisioning |
Automate deployment and upgrade of software images. |
|
Smart zoning |
Reduce consumption of hardware resources and administrative time needed to create and manage zones. |
|
Intelligent diagnostics/Hardware based slow port detection |
Enhance reliability, speed problem resolution, and reduce service costs by using Fibre Channel ping and traceroute to identify exact path and timing of flows, as well as Cisco Switched Port Analyzer (SPAN) and Remote SPAN (RSPAN) and Cisco Fabric Analyzer to capture and analyze network traffic. |
|
Virtual output queuing |
Help ensure line-rate performance on each port by eliminating head-of-line blocking. |
|
High-performance ISLs |
Optimize bandwidth utilization by aggregating up to 16 physical ISLs into a single logical PortChannel bundle with multipath load balancing. |
|
In-Service Software Upgrades |
Reduce downtime for planned maintenance and software upgrades. |
|
Product |
Licenses |
|
Cisco MDS 9000 Family Enterprise Package |
Includes advanced traffic-engineering and network security features such as IVR, QoS and zone-based QoS, Fibre Channel Security Protocol (FC-SP), port security, VSAN-based access control, and fabric binding for open systems. Licensed per switch for all the ports on the switch. |
|
Cisco Prime DCNM for SAN Advanced Edition for Cisco MDS 9100 Series |
Includes advanced management capabilities such as vCenter integration, performance trending, advanced provisioning, backup, and dashboards. Licensed per switch for all the ports on the switch. License is hosted on a server. |
|
Cisco MDS 9148S 12-port On-Demand Activation |
Enables 12 additional Fibre Channel ports (up to 48 total ports on the switch). |
|
Software |
Requirements |
|
Software |
Cisco MDS 9000 NX-OS Software Release 6.2(9) or later supporting Cisco MDS 9148S and Cisco Prime DCNM |
|
Product Name |
Part Number |
|
Base Model Options (See Note 2) |
|
|
Cisco MDS 9148S 16G Multilayer Fabric Switch with 12 enabled ports |
DS-C9148S-12PK9 |
|
Cisco MDS 9148S 16G Multilayer Fabric Switch with 48 enabled ports |
DS-C9148S-48PK9 |
|
Cisco MDS 9148S 16G Multilayer Fabric Switch with 12 enabled ports and 12 x 16G SW SFP+ |
DS-C9148S-D12PSK9 |
|
Cisco MDS 9148S 16G Multilayer Fabric Switch with 48 enabled ports and 48 x 16G SW SFP+ |
DS-C9148S-D48PSK9 |
|
Cisco MDS 9148S 16G Multilayer Fabric Switch with 12 enabled ports and 12 x 8G SW SFP+ |
DS-C9148S-D12P8K9 |
|
Cisco MDS 9148S 16G Multilayer Fabric Switch with 48 enabled ports and 48 x 8G SW SFP+ |
DS-C9148S-D48P8K9 |
|
Component Spares |
|
|
Cisco MDS 9148S 16G Multilayer Fabric Switch with 12 enabled ports, spare |
DS-C9148S-K9= |
|
Cisco MDS 9148S AC Power Supply, spare |
DS-C48S-300AC= |
|
Cisco MDS 9148S Fan Tray, spare |
DS-C48S-FAN= |
|
Configure-to-Order Port License Options (See Note 2) |
|
|
Cisco MDS 9148S 12-port On-Demand Activation license |
M9148S-PL12 |
|
Cisco MDS 9148S 12-port On-Demand Activation license with 12 x 16G SW SFP+ |
M9148S-DPL12PSG |
|
Cisco MDS 9148S 12-port On-Demand Activation license with 12 x 8G SW SFP+ |
M9148S-DPL12P8G |
|
Spare Port Licenses (See Note 1 and Note 2) |
|
|
Cisco MDS 9148S 12-port On-Demand Activation license, spare |
M9148S-PL12= |
|
Cisco MDS 9148S 12-port On-Demand Activation license with 12 x 16G SW SFP+, spare |
M9148S-DPL12PSG= |
|
Cisco MDS 9148S 12-port On-Demand Activation license with 12 x 8G SW SFP+, spare |
M9148S-DPL12P8G= |
|
Cisco MDS 9148S 12-port On-Demand Activation license, eDelivery |
L-M9148S-PL12= |
|
Cisco MDS 9148S 12-port On-Demand Activation Smart license, spare |
M9148S-PL12-SL= |
|
Configure-to-Order Optics Options (See Note 2) |
|
|
Cisco MDS 4/8/16-Gbps Fibre Channel SW SFP+, LC |
DS-SFP-FC16G-SW |
|
Cisco MDS 2/4/8-Gbps Fibre Channel SW SFP+, LC |
DS-SFP-FC8G-SW |
|
Spare Optics (See Note 2) |
|
|
Cisco MDS 4/8/16-Gbps Fibre Channel SW SFP+, LC, spare |
DS-SFP-FC16G-SW= |
|
Cisco MDS 4/8/16-Gbps Fibre Channel LW SFP+, LC, spare |
DS-SFP-FC16G-LW= |
|
Cisco MDS 2/4/8-Gbps Fibre Channel SW SFP+, LC, spare |
DS-SFP-FC8G-SW= |
|
Cisco MDS 2/4/8-Gbps Fibre Channel LW SFP+, LC, spare |
DS-SFP-FC8G-LW= |
|
Cisco MDS 2/4/8-Gbps Fibre Channel Extended Reach SFP+, LC, spare |
DS-SFP-FC8G-ER= |
|
Cisco MDS 2/4/8-Gbps CWDM Long Distance SFP, LC, spare |
DS-CWDM8Gxxxx= |
|
Configure-to-Order Accessory Kit Options |
|
|
Cisco MDS 9148S Accessory Kit for Cisco |
DS-9148S-KIT-CSCO |
|
Cisco MDS 9148S Accessory Kit for EMC |
DS-9148S-KIT-EM |
|
Cisco MDS 9148S Accessory Kit for HDS |
DS-9148S-KIT-HDS |
|
Cisco MDS 9148S Accessory Kit for IBM |
DS-9148S-KIT-IBM |
|
Cisco MDS 9148S Accessory Kit for HP |
DS-9148S-KIT-HP |
|
Accessory Kit Spare |
|
|
Cisco MDS 9148S Accessory Kit, spare |
DS-9148S-KIT-CSCO= |
|
Configure-to-Order Power Cord Options |
|
|
Power Cord, 250VAC 10A IRAM 2073 Plug, Argentina |
CAB-9K10A-AR |
|
Power Cord, 250VAC 10A 3112 Plug, Australia |
CAB-9K10A-AU |
|
Power Cord, 250VAC 10A GB1002 Plug, China |
CAB-9K10A-CH |
|
Power Cord, 250VAC 10A CEE 7/7 Plug, EU |
CAB-9K10A-EU |
|
Power Cord, 250VAC 10A SI16S3 Plug, Israel |
CAB-9K10A-ISR |
|
Power Cord, 250VAC 10A CEI 23-16/VII Plug, Italy |
CAB-9K10A-IT |
|
Power Cord, 125VAC 13A KSC8305 Plug, Korea |
CAB-9K10A-KOR |
|
Power Cord, 250VAC 10A SABS 164/1 Plug, South Africa |
CAB-9K10A-SA |
|
Power Cord, 250VAC 10A, Straight C15, MP232 Plug, SWITZ |
CAB-9K10A-SW |
|
Power Cord, 125VAC 15A CNS10917-2, Taiwan |
CAB-9K10A-TWN |
|
Power Cord, 250VAC 10A BS1363 Plug (13 A fuse), UK |
CAB-9K10A-UK |
|
Power Cord, 125VAC 13A NEMA 5-15 Plug, North America |
CAB-9K12A-NA |
|
Power Cord, 250VAC 10A, Brazil |
CAB-250V-10A-BR |
|
Cabinet Jumper Power Cord, 250 VAC 13A, C14-C15 Connectors |
CAB-C15-CBN |
|
Spare Power Cords |
|
|
Power Cord, 250VAC 10A IRAM 2073 Plug, Argentina, spare |
CAB-9K10A-AR= |
|
Power Cord, 250VAC 10A 3112 Plug, Australia, spare |
CAB-9K10A-AU= |
|
Power Cord, 250VAC 10A GB1002 Plug, China, spare |
CAB-9K10A-CH= |
|
Power Cord, 250VAC 10A CEE 7/7 Plug, EU, spare |
CAB-9K10A-EU= |
|
Power Cord, 250VAC 10A SI16S3 Plug, Israel, spare |
CAB-9K10A-ISR= |
|
Power Cord, 250VAC 10A CEI 23-16/VII Plug, Italy, spare |
CAB-9K10A-IT= |
|
Power Cord, 125VAC 13A KSC8305 Plug, Korea, spare |
CAB-9K10A-KOR= |
|
Power Cord, 250VAC 10A SABS 164/1 Plug, South Africa, spare |
CAB-9K10A-SA= |
|
Power Cord, 250VAC 10A, Straight C15, MP232 Plug, SWITZ, spare |
CAB-9K10A-SW= |
|
Power Cord, 125VAC 15A CNS10917-2, Taiwan, spare |
CAB-9K10A-TWN= |
|
Power Cord, 250VAC 10A BS1363 Plug (13 A fuse), UK, spare |
CAB-9K10A-UK= |
|
Power Cord, 125VAC 13A NEMA 5-15 Plug, North America, spare |
CAB-9K12A-NA= |
|
Power Cord, 250VAC 10A, Brazil, spare |
CAB-250V-10A-BR= |
|
Cabinet Jumper Power Cord, 250 VAC 13A, C14-C15 Connectors, spare |
CAB-C15-CBN= |
|
Configure-to-Order Advanced Software Package Options (See Note 3) |
|
|
Cisco MDS Enterprise Package for one MDS 9100 Series Switch |
M9100ENT1K9 |
|
Cisco Prime DCNM for SAN Advanced Edition for MDS 9100 |
DCNM-SAN-M91-K9 |
|
Spare Advanced Software Packages (See Note 1 and Note 3) |
|
|
Cisco MDS Enterprise Package for one MDS 9100 Series Switch, spare |
M9100ENT1K9= |
|
Cisco MDS Enterprise Package for one MDS 9100 Series Switch, eDelivery |
L-M9100ENT1K9= |
|
Cisco Prime DCNM for SAN Advanced Edition for MDS 9100, spare |
DCNM-SAN-M91-K9= |
|
Cisco Prime DCNM for SAN Advanced Edition for MDS 9100, eDelivery |
L-DCNM-S-M91-K9= |
